Piezoresistive Pressure Sensors   Click on images for enlarged view

Die
3000 Series low pressure
PSI 5 - 100
 Bar 0.34 - 7
 KPa 34.5 - 689.5
 mm 3.3 x 2.5
AP301 Series medium pressure
PSI 100 - 1,000
 Bar 7 - 69
 KPa 689.5 - 6,895
 mm 2.8 x 2.2
5000 Series high pressure
PSI 1,000 - 10,000
 Bar 138 - 689
 KPa 13,790 - 68,948
 mm 1.9x 1.6
7000 Series broad pressure
PSI 15 - 500
 Bar 1 - 34.5
 KPa 103 - 3,447
 mm 2.2 x 1.6
HM Series harsh media, absolute
PSI 100 - 500
 Bar 7 - 34.5
 KPa 700 - 3,447
 mm 2.2 x 1.9
  Uncompensated Packages
SMD Series surface-mountable,
7.6mm2
PSI 5 - 500+
 Bar .34 - 34.5+
 KPa 34.5 - 3,447+
MS Series surface-mountable,
6.4mm2
PSI 15 - 500+
 Bar 1 - 34.5+
 KPa 103 - 3,447+

Blood Pressure Packages
BP Series disposable medical,compensated
mmHg -30 - 300
 PSI -.58 to 5.8
 mbar 40 - 400
 KPa 4 - 40

Laser-Trimmed Packages
Custom solutions available
upon request

Product Ordering Guide
